Kia Cerato IV (2018-2022) m/t, w/ smart key Wiring diagram
This page shows the only wiring diagram for the component.m/t, w/ smart key, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram m/t, w/ smart key (1 of 1)
1.6L
1.6L, 2.0L
A/V, NAVIGATION HEAD UNIT
AUX, USB JACK
BACKUP LAMP SWITCH
BLK WIRE
BLOWER MOTOR
BRAKE FLUID LEVEL SENSOR
COOLING FAN 1 RELAY
COOLING FAN MOTOR
DATA LINK CONNECTOR
DRL LP LED OPT
E/R JUNCTION BLOCK
E/R-C
EXTERNAL BUZZER
FOG LP OPT
FORWARD COLLISION AVOIDANCE ASSIST UNIT
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR
HORN (HIGH)
HORN (LOW)
IBU
ICU JUNCTION BLOCK IPS CONTROL MODULE
ICU-B
IGNITION LOCK, CLUTCH SWITCH
LED BULB
LEFT DRL
LEFT FRONT FOG LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP
M/T
M/T, W/ SMART KEY
MULTI- FUNCTION SWITCH
NCA WIRE
PCB BLOCK
PDM 2 (ACC) RELAY
POWER OUTLET RELAY
START/STOP BUTTON SWITCH
STOP LAMP SWITCH
W/ NAVIGATION
W/ SMART KEY
W/O LED
Go to component -> Ground distribution circuit (2 of 5) -> M/T, W/ SMART KEY
