Kia Cerato IV (2018-2022) door open ind Wiring diagram
This page shows the only wiring diagram for the component.door open ind, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram door open ind (1 of 1)
1.6L, 2.0L
ABS IND.
AIR BAG
AIR BAG IND
AMP IC
AUTO STOP IND
BLK WIRE
BLU WIRE
BRAKE IND
BRN WIRE
C-CAN TRANSCEIVER
CHARGE IND
CHECK ENGINE IND
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CONSTANT CURRENT
CRUISE IND
DIAL LED
DIMMING CIRCUIT
DOOR OPEN IND
DRV MD
ESC IND
ESC OFF IND
FCA OFF IND
FRONT FOG IND
FUEL
FUEL GAUGE
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HIGH BEAM IND
HOT IN ON OR START
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-E
ICU-F
IMMO IND
KEY OUT IND
LED HEADLAMP IND
LEFT
LOW BEAM IND
LOW FUEL IND
LOW WASHER IND
M-CAN TRANSCEIVER
M/T
MDPS IND
MEM PWR
MEMORY 1 FUSE
MICOM
NEUTRAL
NEUTRAL SWITCH
OIL LEVEL IND
OIL PRESS
OIL PRESSURE IND
ON/ST I/P
ORG/ WIRE
PARKING
PNK WIRE
PNK/BLK WIRE
POINTER LED
RED WIRE
RIGHT
SEAT BELT IND
SEG LCD LED
SENDER
SPD LCD (3.5 INCH)
SPEAKER
SPEEDOMETER
SUPPLEMENTAL RESTRAINTS SYSTEM
SW IN
SW+
TACHOMETER
TAIL ON IND
TEMPERATURE GAUGE
TO PIN 13 (DIAGRAM 2 OF 3)
TPMS IND
TRIP
TRUNK OPEN IND
TURN IND
WHT WIRE
Go to component -> Instrument cluster circuit, seg lcd (1 of 3) -> DOOR OPEN IND
