Kia Cerato IV (2018-2022) auto defogger actuator open Wiring diagram
This page shows the only wiring diagram for the component.auto defogger actuator open, which is found in the car Kia Cerato IV (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto defogger actuator open (1 of 1)
A/C CONTROL MODULE
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER ACTUATOR CLOSE
AUTO DEFOGGER ACTUATOR F/B
AUTO DEFOGGER ACTUATOR OPEN
AUTO DEFOGGER SENS(+)
AUTO DEFOGGER SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DRIVER POWER OUTSIDE MIRROR
E/R JUNCTION BLOCK
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HEATED MIRROR FUSE
HOT AT ALL TIMES
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-B
ICU-C
ICU-F
ICU-G
IND
IPS CONTROL MODULE
MODULE 5 FUSE
MULTI FUSE 2
NCA WIRE
OFF
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RLY REAR CTRL DEFOGGER SW I/P
SENSOR GND
SENSOR PWR
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit, w/ auto defogger -> AUTO DEFOGGER ACTUATOR OPEN
