Kia Cerato III facelift (2016-2021) w/ uvo audio Wiring diagram
This page shows the only wiring diagram for the component.w/ uvo audio, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ uvo audio (1 of 1)
4 DOOR
A/V, NAVIGATION HEAD UNIT
AIR BAG IND
BATTERY CHARGE
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
CRUISE IND
DRIVE MODE SWITCH IN
DRIVER DOOR SWITCH
ECO (GREEN) IND
EEPROM
FROM DOT LCD BACK ILL (DIAGRAM 1 OF 3)
FRONT FOG IND
FUEL LCD
GRN WIRE
GRY WIRE
ICE WARNING IN
INSTRUMENT CLUSTER
INTERFACE/LED DRIVER IC
LEFT "C" PILLAR)
LEFT REAR DOOR SWITCH
M-CAN
MEMORY PWR
MICOM
OIL PRESSURE
ORG/ WIRE
PARKING BRAKE SIG
PASSENGER DOOR SWITCH
RIGHT REAR DOOR SWITCH
SET IND
SIGNAL GROUND 1
SIGNAL GROUND 2
SPEEDOMETER
STEERING WHEEL IN
TACHO- METER
TAIL ON IND
TEMP LCD
TFT LCD
TRANSCEIVER/
TRIP
TRIP SW 1 (+)
TRIP SW 2 (+)
W/ UVO AUDIO
WASHER FLUID
Go to component -> Instrument cluster circuit (3 of 3) -> W/ UVO AUDIO
