Kia Cerato III facelift (2016-2021) turn signal lamp switch Wiring diagrams
This page contains all the electrical diagrams for the component. turn signal lamp switch, in which he is found in the car Kia Cerato III facelift (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram turn signal lamp switch (1 of 2)
AUTO
B-CAN HIGH
B-CAN LOW
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HAZARD SWITCH
HEAD
ILL
LAMP
LEFT "C" PILLAR)
LEFT HEADLAMP
LEFT REAR COMBINATION LAMP (OUT)
LIGHT SWITCH
MARKER
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
OPERATION SOUND
ORG/ WIRE
PARKING
PNK WIRE
RED WIRE
RED/ORG WIRE
RIGHT HEADLAMP
SIDE
STOP
STOP LAMP SIG
TAIL
TAIL LAMP
TAIL LAMP SW
TURN
TURN SIGNAL LAMP SOUND RELAY
TURN SIGNAL LAMP SWITCH
W/ LED
W/O LED
Go to component -> Exterior lamps circuit, 4 door (1 of 4) -> TURN SIGNAL LAMP SWITCH
