Kia Cerato III facelift (2016-2021) turn sig lamp switch sig Wiring diagram
This page shows the only wiring diagram for the component.turn sig lamp switch sig, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn sig lamp switch sig (1 of 1)
ARISU-LT
B+1 FUSE
B+2 FUSE
B-CAN
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CONTROL
E/R JUNCTION BLOCK
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
HAZARD RH SW SIG
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-C
I/P-F
IPS CONTROL MODULE
LAMP
LEFT "C" PILLAR)
LH TAIL LAMP
LOW HIGH
MEMORY POWER
MODULE 7 FUSE
MULTI FUSE
NCA WIRE
ORG/ WIRE
RED WIRE
RED/ORG WIRE
RH TAIL LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
SMART JUNCTION BLOCK
STOP
T/SIG FL
T/SIG FR
TAIL LAMP
TURN
TURN SIG LAMP SOUND RLY CONTROL
TURN SIG LAMP SWITCH SIG
W/ LED
W/O LED
WHT WIRE
Go to component -> Exterior lamps circuit, 4 door (2 of 4) -> TURN SIG LAMP SWITCH SIG
