Kia Cerato III facelift (2016-2021) smart key trunk antenna Wiring diagram
This page shows the only wiring diagram for the component.smart key trunk antenna, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram smart key trunk antenna (1 of 1)
2.0L GDI M/T 2.0L GDI A/T
2.0L MPI
4 DOOR
5 DOOR
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE LIGHT
BRAKE LIGHT SWITCH
BRAKE SWITCH FUSE
CENTER REAR OF LUGGAGE COMPT)
ECM (M/T) PCM (A/T) (LEFT REAR OF ENGINE COMPT)
EMS COM
ENGINE RPM OUTPUT
ESC UNIT ESC MODULE
GRN WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
I/P-E
I/P-F
IMMO IND
INSTRUMENT CLUSTER
LEAK CURRENT AUTO CUT DEVICE
LED
LOCK
LP SW
MEMORY FUSE
NCA WIRE
ORG/ WIRE
OUTPUT (FR)
PNK WIRE
PNK/BLK WIRE
RED WIRE
SMART JUNCTION BLOCK
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY BUMPER ANTENNA
SMART KEY TRUNK ANTENNA
STOP LAMP SWITCH
STOP LP SIG
STOP SIGNAL ELECTRONIC MODULE
SWITCH
VEHICLE SPEED INPUT
WHEEL SENS
YEL WIRE
Go to component -> Immobilizer circuit, w/ smart key system (2 of 3) -> SMART KEY TRUNK ANTENNA
