Kia Cerato III facelift (2016-2021) rear wiper relay icm relay box Wiring diagram

5 DOOR A/C CONTROL MODULE A/CON FUSE AUTOMATIC A/C BCM BLK WIRE BLOWER RELAY BURGLAR ALARM HORN RELAY CLUSTER IONIZER DEICER FUSE DRIVER AIR VENTILATION SEAT CONTROL MODULE DRIVER SEAT WARMER MODULE E/R JUNCTION BLOCK (LEFT SIDE OF ENGINE COMPT) FROM IGNITION SWITCH (DIAGRAM 6 OF 11) FRONT DEICER RELAY GRN WIRE GRY WIRE GSL PTC HEATER FUSE GSL PTC HEATER RELAY HORN FUSE HORN RELAY HTD STRG FUSE I/P-B I/P-E I/P-F I/P-G ICM RELAY BOX (TOP LEFT SIDE OF DASH) IPS CONTROL MODULE LEFT REAR SEAT WARMER MANUAL A/C MODULE 5 FUSE MODULE 8 FUSE MULTI- FUNCTION SWITCH NCA WIRE ON INPUT ORG/ WIRE ORG/BLK WIRE PASSENGER AIR VENTILATION SEAT CONTROL MODULE PASSENGER SEAT WARMER MODULE PNK WIRE REAR WIPER MOTOR REAR WIPER RELAY ICM RELAY BOX RED WIRE RIGHT REAR SEAT WARMER S/HEATER FRT FUSE SMART KEY CONTROL MODULE STEERING WHEEL HEATER STOP LAMP FUSE STOP SIGNAL ELECTRONIC MODULE SUNROOF TO SMART JUNCTION BLOCK (DIAGRAM 10 OF 11) VACUUM PUMP VACUUM PUMP FUSE W/ AIR VENTILATION W/ BURGLAR ALARM W/ SMART KEY W/O AIR VENTILATION W/O SMART KEY WHT WIRE WIPER FRT FUSE WIPER FRT RELAY WIPER MOTOR WIPER RR FUSE
