Kia Cerato III facelift (2016-2021) overhead console Wiring diagram
This page shows the only wiring diagram for the component.overhead console, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead console (1 of 1)
BCM
BLK WIRE
BRN WIRE
CLICK
CLOSE
CLOSE/ TILT DOWN
GLASS STATUS
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
I/P-E
I/P-G
MEMORY POWER
MODULE 5 FUSE
NCA WIRE
ON INPUT
ORG/ WIRE
OVERHEAD CONSOLE
PNK WIRE
SERIAL COMN GLASS STATUS SIG
SIG A
SIG B
SIG C
SIG/SERIAL
SMART JUNCTION BLOCK
SUNROOF (IN OVERHEAD CONSOLE)
SUNROOF FUSE
SUNROOF SWITCH
TILT UP
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> OVERHEAD CONSOLE
