Kia Cerato III facelift (2016-2021) low low high high Wiring diagram
This page shows the only wiring diagram for the component.low low high high, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low low high high (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
GRN WIRE
GRN/BLK WIRE
HIGH LOW LOW HIGH
INSTRUMENT CLUSTER
LEFT BLIND SPOT DETECTION RADAR
LOCAL CAN HIGH
LOCAL CAN LOW
LOCAL- LOCAL- C-CAN CAN CAN HIGH LOW HIGH
LOW HIGH
LOW LOW HIGH HIGH
M-CAN
ORG/ WIRE
ORG/BLK WIRE
REAR OF TRUNK)
RED WIRE
RED/ORG WIRE
RIGHT BLIND SPOT DETECTION RADAR
SRS CONTROL MODULE
W/ NAVIGATION W/O NAVIGATION W/ UVO
WHT WIRE
Go to component -> Computer data lines circuit (2 of 5) -> LOW LOW HIGH HIGH
