Kia Cerato III facelift (2016-2021) left warning output Wiring diagram
This page shows the only wiring diagram for the component.left warning output, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left warning output (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
BSD IND
BSD SWITCH
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
DRIVER POWER OUTSIDE MIRROR
GRN WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HOT IN ON OR START
I/P-E
ILL
LEFT "C" PILLAR)
LEFT BLIND SPOT DETECTION RADAR
LEFT WARNING OUTPUT
LOCAL CAN HIGH
LOCAL CAN LOW
MODULE 4 FUSE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK/BLK WIRE
PNK/ORG WIRE
REAR OF TRUNK)
RIGHT BLIND SPOT DETECTION RADAR
RIGHT WARNING OUTPUT
SMART JUNCTION BLOCK
WHT WIRE
Go to component -> Blind spot information system circuit -> LEFT WARNING OUTPUT
