Kia Cerato III facelift (2016-2021) hall effect sensor Wiring diagram
This page shows the only wiring diagram for the component.hall effect sensor, which is found in the car Kia Cerato III facelift (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hall effect sensor (1 of 1)
AUTO
AUTO DOWN DOWN
B+ GND
BCM (CENTER OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COM
DOOR LOCK SWITCH
DOOR LOCKS SYSTEM
DOWN
DOWN UP
DRIVER SAFETY POWER WINDOW MODULE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HALL EFFECT SENSOR
ILL
MEMORY PWR COM
OFF
PASSENGER POWER WINDOW SWITCH
PASSENGER SAFETY POWER WINDOW MODULE
PNK WIRE
PNK/BLK WIRE
RELAY
REVERSE PROTECTION, FILTER
SAFETY PWR WINDOW ENABLE OUTPUT
SHUNT RESISTOR
SIG FILTER
UP AUTO UP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power windows circuit, w/ auto up/down power window (3 of 3) -> HALL EFFECT SENSOR
