Kia Carnival IV facelift (2023-2024) unlatch right return Wiring diagram
This page shows the only wiring diagram for the component.unlatch right return, which is found in the car Kia Carnival IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unlatch right return (1 of 1)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CLUTCH FEED(+)
DRIVE CLUTCH GND
DRIVE MOTOR CLOSE
DRIVE MOTOR OPEN
E/R JUNCTION BLOCK
GRN WIRE
GROUND
GRY WIRE
GRY/ORG WIRE
HIGH POWER BATTERY
HOT AT ALL TIMES
LEFT CLUTCH +
LEFT CLUTCH RETURN
LEFT DRIVE UNIT (BEHIND LEFT REAR QUARTERPANEL)
LEFT MOTOR CLOSE
LEFT MOTOR OPEN
LEFT PINCH SENSOR
LEFT QUAD SENSOR GROUND
LEFT QUAD SENSOR POWER
LEFT SLIDING DOOR ANTI PINCH SENSOR
LEFT UNLATCH
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
ORG/ WIRE
PINCH SENSOR RETURN
PNK WIRE
PNK/BLK WIRE
POSI SENS 1
POSI SENS 2
POSI SENS POWER
POSI SENS RETURN
POSI SENS RTN
POWER SLIDING DOOR MODULE (BEHIND LEFT REAR QUARTERPANEL)
RED WIRE
RIGHT B-PILLAR SW
RIGHT CHILD LOCK SW
RIGHT CLUTCH +
RIGHT CLUTCH RETURN
RIGHT DETENT SW
RIGHT DRIVE UNIT (BEHIND RIGHT REAR QUARTERPANEL)
RIGHT INSIDE HANDLE SW CLOSE
RIGHT INSIDE HANDLE SW OPEN
RIGHT MOTOR CLOSE
RIGHT MOTOR OPEN
RIGHT OUTSIDE HNDL SW
RIGHT PINCH SENSOR
RIGHT POWER SLIDING DOOR SW
RIGHT PRIMARY SW
RIGHT QUAD SENSOR GND
RIGHT QUAD SENSOR POWER
RIGHT SLIDING DOOR ANTI PINCH SENSOR
RIGHT UNLATCH
UNLATCH LEFT RETURN
UNLATCH RIGHT RETURN
WHT WIRE
YEL WIRE
Go to component -> Power sliding door circuit (1 of 3) -> UNLATCH RIGHT RETURN
