Kia Carnival IV facelift (2023-2024) steering wheel steering wheel heated module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel steering wheel heated module, which is found in the car Kia Carnival IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel steering wheel heated module (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
CARGO LAMP
CENTER ROOM LAMP
CLOCKSPRING
CLOCKSPRING (STEERING WHEEL REMOTE CONTROL SWITCH)
DATA LINK CONNECTOR
ELECTROCHROMIC MIRROR
FRONT SUNROOF MOTOR
FRONT SUNROOF SWITCH 1
FRONT SUNROOF SWITCH 2
GRY WIRE
ICU BACKUP GND
ICU MAIN GND
ICU-F
ICU-G
INSTRUMENT CLUSTER
IPS CONTROL MODULE
LANE DEPARTURE WARNING (LDW) CAMERA
LEFT FRONT TRAY POWER OUTLET
LEFT PERSONAL LAMP
LEFT VANITY LAMP
MULTI- FUNCTION SWITCH
NCA WIRE
OVERHEAD CONSOLE
OVERHEAD CONSOLE INDICATOR
PPL/ORG WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RAIN SENSOR
REAR A/C CONTROL MODULE
REAR ROOM LAMP
REAR SUNROOF SWITCH
RIGHT FRONT TRAY POWER OUTLET
RIGHT PERSONAL LAMP
RIGHT VANITY LAMP
STEERING WHEEL STEERING WHEEL HEATED MODULE
W/ 12.3 INCH TFT LCD
W/ 4.2 INCH TFT LCD
W/ SUNROOF
W/O SUNROOF
WHT WIRE
WIRELESS CHARGER
WIRELESS CHARGER INDICATOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 10) -> STEERING WHEEL STEERING WHEEL HEATED MODULE
