Kia Carnival IV facelift (2023-2024) signal ground 1 Wiring diagrams
This page contains all the electrical diagrams for the component. signal ground 1, in which he is found in the car Kia Carnival IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram signal ground 1 (1 of 2)
12.3 INCH TFT
AMP
AMP IC
BLK WIRE
BLU WIRE
BLU/RED WIRE
BUCK CONVERTER
COMPUTER DATA LINES SYSTEM
E-CAN
GPU
GRN/WHT WIRE
GRY/ORG WIRE
INSTRUMENT CLUSTER
LEFT REVERSE PARKING DISTANCE WARNING SENSOR
LEFT REVERSE PARKING DISTANCE WARNING SENSOR (CENTER)
LEFT REVERSE PARKING DISTANCE WARNING SENSOR (SIDE)
LIN
M-CAN
MICOM
MUC REG
ORG/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT REVERSE PARKING DISTANCE WARNING SENSOR
RIGHT REVERSE PARKING DISTANCE WARNING SENSOR (CENTER)
RIGHT REVERSE PARKING DISTANCE WARNING SENSOR (SIDE)
SIGNAL GROUND 1
SPEAKER
TFT LCD DRIVE
TRANSCEIVER/
VIDEO SIG (INPUT)
W/ 12.3 INCH TFT LCD
W/ 4.2 INCH TFT LCD
WHT/BLK WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit, w/ adas (3 of 3) -> SIGNAL GROUND 1
Wiring diagram signal ground 1 (2 of 2)
12.3 INCH TFT
AMP
AMP IC
BLK WIRE
BLU WIRE
BUCK CONVERTER
COMPUTER DATA LINES SYSTEM
E-CAN TRANSCEIVER
GPU
GRN/WHT WIRE
GRY/ORG WIRE
INSTRUMENT CLUSTER
LEFT PARKING DISTANCE WARNING REVERSE SENSOR
LEFT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER)
LIN
M-CAN TRANSCEIVER
MICOM
ORG/BLK WIRE
RED WIRE
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT PARKING DISTANCE WARNING- REVERSE SENSOR (CENTER)
SIGNAL GROUND 1
SPEAKER
TFT LCD DRIVE
W/ 12.3 INCH TFT LCD
W/ 4.2 INCH TFT LCD
WHT/BLK WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit, w/o adas (2 of 2) -> SIGNAL GROUND 1
