Kia Carnival IV facelift (2023-2024) passenger rear height adjuster motor Wiring diagrams
This page contains all the electrical diagrams for the component. passenger rear height adjuster motor, in which he is found in the car Kia Carnival IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger rear height adjuster motor (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BWD
DOWN
GRN WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
MEMORY POWER
P/SEAT PASS FUSE
PASSENGER FRONT HEIGHT ADJUSTER MOTOR
PASSENGER POWER SEAT SWITCH
PASSENGER REAR HEIGHT ADJUSTER MOTOR
PASSENGER RECLINING MOTOR
PASSENGER SLIDE MOTOR
POWER GROUND
RED WIRE
W/ SEAT WARMER
W/O SEAT WARMER
YEL WIRE
YEL/RED WIRE
Go to component -> Passenger power seat circuit, w/o walk-in switch -> PASSENGER REAR HEIGHT ADJUSTER MOTOR
Wiring diagram passenger rear height adjuster motor (2 of 2)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BWD
DOWN
GRN WIRE
GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
LT GRN WIRE
MEMORY POWER
P/SEAT PASS FUSE
PASSENGER FRONT HEIGHT ADJUSTER MOTOR
PASSENGER POWER SEAT SWITCH
PASSENGER REAR HEIGHT ADJUSTER MOTOR
PASSENGER RECLINING MOTOR
PASSENGER SLIDE MOTOR
PASSENGER WALK IN SWITCH
PASSENGER WALK-IN MODULE (UNDER FRONT PASSENGER'S SEAT)
POWER GROUND
RECLINING (BWD) UP
RECLINING FWD
RECLINING MTR
RECLINING MTR (BWD) POWER GROUND
RECLINING MTR (FWD) POWER GROUND
RECLINING MTR SWITCH (BWD)
RECLINING MTR SWITCH (FWD)
RED WIRE
SLIDE (FWD) UP
SLIDE BWD
SLIDE MOTOR
SLIDE MOTOR (BWD)
SLIDE MOTOR (FWD)
SLIDE MOTOR SWITCH (BWD)
SLIDE MOTOR SWITCH (FWD)
WALK IN RECLINING MTR (BWD)
WALK IN RECLINING MTR (FWD)
WALK IN SLIDE MTR (BWD)
WALK IN SLIDE MTR (FWD)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Passenger power seat circuit, w/ walk-in switch -> PASSENGER REAR HEIGHT ADJUSTER MOTOR
