Kia Carnival IV facelift (2023-2024) off auto Wiring diagram
This page shows the only wiring diagram for the component.off auto, which is found in the car Kia Carnival IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off auto (1 of 1)
B+2 FUSE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
B-CAN LOW LIGHT SW SIG
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DEDI DRL LH
DEDI DRL RH
E/R JUNCTION BLOCK
FRT FOG
FRT FOG LAMP SW IN
FRT FOG LAMP SW SIG
GND (BCM)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
H/LP HI LH
H/LP HI RH
H/LP LO LH
H/LP LO RH
HDLP HIGH SW IN
HDLP HIGH SW OUT
HDLP LOW BACKUP SIG
HDLP LOW BACKUP SW OUT
HEADLAMP
HOT AT ALL TIMES
IBU (RIGHT SIDE OF HVAC UNIT)
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-F
ICU-H
IPS 1
IPS 2
IPS 3
IPS CONTROL MODULE
LEFT FRONT FOG LAMP
LH LOW TELLTALE SW
LIGHT SW OUT
MULTI- FUNCTION SWITCH
NCA WIRE
OFF AUTO
ORG/ WIRE
ORG/BLK WIRE
PASSING DIMMER
PNK/BLK WIRE
RED WIRE
RELAY ENERGIZED
RH LOW TELLTALE SW
RIGHT FRONT FOG LAMP
TAIL
WHT/ORG WIRE
WIPER, LIGHT GND
YEL WIRE
YEL/ORG WIRE
Go to component -> Headlamps circuit (1 of 2) -> OFF AUTO
