Kia Carnival IV facelift (2023-2024) e/r junction block Wiring diagrams

B+3 FUSE BCW IND BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER POWER OUTSIDE MIRROR E-CAN HIGH E-CAN LOW E/R JUNCTION BLOCK GRN WIRE GROUND HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-B ICU-C L-CAN HIGH L-CAN LOW LEFT REAR RADAR LH BCW IND MEMORY POWER MODULE 3 FUSE NCA WIRE ON/START INPUT ORG/ WIRE PASSENGER POWER OUTSIDE MIRROR PNK WIRE RED WIRE RELAY ENERGIZED RH BCW IND RIGHT REAR RADAR YEL WIRE YEL/ORG WIRE

12.3 INCH TFT ALT FUSE ALT LIN ALTERNATOR AMS FUSE BATTERY BATTERY JUNCTION BLOCK BATTERY SENSOR BLK WIRE BLK/ORG WIRE BUCK CONVERTER CHARGE IND CLUSTER FUSE COMPUTER DATA LINES SYSTEM E-CAN E-CAN HIGH E-CAN LOW E/R JUNCTION BLOCK GPU GRN/WHT WIRE GRY WIRE GRY/ORG WIRE HOT IN ON OR START ICU JUNCTION BLOCK ICU-A ICU-F ICU-H INSTRUMENT CLUSTER INTERFACE IPS CONTROL MODULE LIN LIN B LIN LINE M-CAN MCU REG MICOM P-CAN HIGH P-CAN LOW RED WIRE RED/WHT WIRE SNSR STARTING CIRCUIT TRANSCEIVER/ W/ 12.3 INCH TFT LCD W/ 4.2 INCH TFT LCD WHT WIRE WHT/BLK WIRE YEL/WHT WIRE

ACC RELAY BLK WIRE BRAKE FLUID LEVEL SENSOR COOLING FAN MOTOR E/R JUNCTION BLOCK E/R-B ESC MODULE EXTERNAL BUZZER FRONT RADAR UNIT FRONT WIPER (LOW) RELAY FRONT WIPER HIGH RELAY HOOD SWITCH HORN (HIGH) HORN (LOW) LEFT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER) LEFT PARKING DISTANCE WARNING FORWARD SENSOR (SIDE) NCA WIRE POWER OUTLET RELAY RIGHT PARKING DISTANCE WARNING FORWARD SENSOR RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (CENTER) RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (SIDE) SCU (SHIFT BY WIRE CONTROL UNIT) STOP LAMP SWITCH W/ PDW/RSPA W/ SBW W/ SMART KEY WASHER LEVEL SENSOR

A/C PRESSURE TRANSDUCER APS 1 GND APS 2 GND APT GND APT SIG BLK WIRE BLU WIRE BLU/BLK WIRE BRAKE LAMP SW BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM COOLING FAN PWM CTRL COOLING FANS SYSTEM E/R JUNCTION BLOCK ECM (LEFT REAR OF ENGINE COMPT) ENG CNTRL RLY ON I/P ENG CTRL RLY CTRL ENGINE RPM ESC MODULE ETC MOTOR OUT (+) FUEL PUMP FUSE FUEL PUMP RELAY GRN WIRE GRN/BLK WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES IBU ICU JUNCTION BLOCK ICU-F IGN COIL CTRL 1 IGN COIL CTRL 3 IMMO K-LINE INJECTOR CTRL (MPI) 5 KNOCK SENS 1 LOW KNOCK SENS 2 LOW LIN O/P (FR RH) ORG/ WIRE ORG/BLK WIRE OXYGEN SENS 3 HEATER P-CAN HIGH P-CAN LOW PIC INTERFACE PNK WIRE PRESS SENS SIG RED WIRE RED/BLK WIRE RELAY ENERGIZED SENS HEATER (OXYGEN SENS) 1 SENS I/P TEMP SENS SIG TPS 1 SIG TPS GND VEHICLE SPEED W/ IMMO / SMART KEY W/O IMMO, SMART KEY WHEEL SPEED WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
