Kia Carnival IV facelift (2023-2024) driver reclining switch Wiring diagram
This page shows the only wiring diagram for the component.driver reclining switch, which is found in the car Kia Carnival IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver reclining switch (1 of 1)
B-CAN
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN/YEL WIRE
BWD
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (CENTER OF DRIVER'S DOOR)
DRIVER FRONT HEIGHT ADJUSTER SWITCH
DRIVER LUMBAR SUPPORT MOTOR (FWD/BWD)
DRIVER LUMBAR SUPPORT MOTOR (UP/DOWN)
DRIVER LUMBAR SUPPORT SWITCH (UP/DOWN)
DRIVER POWER SEAT SWITCH
DRIVER REAR HEIGHT ADJUSTER SWITCH
DRIVER RECLINING SWITCH
DRIVER SLIDE SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ILL
IMS SW
IMS SWITCH
MCU
MEMORY 9 FUSE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REGULATOR
SET-
TRANSCEIVER/
VCC
VOLTAGE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Memory seat circuit (3 of 3) -> DRIVER RECLINING SWITCH
