Cooling fan circuit for Kia Carnival IV (2020-2024)

A/C PRESSURE TRANSDUCER APT GND APT SIG APT SUPPLY BATT + BLDC (BRUSHLESS DC) MOTOR COOLING FAN MOTOR BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN FUSE COOLING FAN PWM OUTPUT E/R JUNCTION BLOCK E/R-B E/R-C ECTS IN GND ECTS IN SIG ECTS OUT GND ECTS OUT SIG ENGINE CONTROL RELAY ENGINE COOLANT TEMPERATURE SENSOR (IN) ENGINE COOLANT TEMPERATURE SENSOR (OUT) GRN WIRE GRY WIRE HOT AT ALL TIMES IGN MAIN RLY CTRL MULTI FUSE (TYPE A) NCA WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PNK WIRE PWM SIG RED WIRE SENSOR 4 FUSE WHT WIRE WHT/BLK WIRE
