Immobilizer circuit, w/o smart key system for Kia Carnival IV (2020-2024)

12.3 INCH TFT 4.2 INCH TFT LCD B+ ECU BLK WIRE BLK/ORG WIRE BLU WIRE BUCK- CLUSTER FUSE COMPUTER DATA LINES SYSTEM CONVERTER) E-CAN ECU GROUND GPU GRN WIRE GRN/WHT WIRE GROUND SIG 1 GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START IBU IBU 1 FUSE IBU 2 FUSE ICU JUNCTION BLOCK ICU-F IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH IMMO IMMO IND INSTRUMENT CLUSTER INTER- FACE M-CAN MICOM NCA WIRE ON/ST INPUT ORG/BLK WIRE P-CAN HIGH P-CAN LOW RED WIRE RIGHT END OF DASH) TRANSCEIVER/ WHT/BLK WIRE YEL/WHT WIRE
