Kia Carnival IV (2020-2024) w/o dynamic guide camera Wiring diagrams

This page contains all the electrical diagrams for the component. w/o dynamic guide camera, in which he is found in the car Kia Carnival IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/o dynamic guide camera (1 of 3)

Wiring diagram w/o dynamic guide camera for Kia Carnival IV (2020-2024)

Get access

BLK WIRE BLK/ORG WIRE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE HAZARD SWITCH LICENSE LAMP NCA WIRE ORG/BLK WIRE RED WIRE RIGHT REAR COMBINATION LAMP (IN) RIGHT REAR COMBINATION LAMP (OUT) STOP LAMP TAIL LAMP TAIL, SIDE MARKER LAMP W/ DYNAMIC GUIDE CAMERA W/ LED W/ NAVIGATION W/ SURROUND VIEW MONITOR W/O DYNAMIC GUIDE CAMERA W/O LED W/O NAVIGATION W/O SURROUND VIEW MONITOR YEL WIRE YEL/BLK WIRE

Go to component: -> Exterior lamps circuit (4 of 5) -> W/O DYNAMIC GUIDE CAMERA

Wiring diagram w/o dynamic guide camera (2 of 3)

Wiring diagram w/o dynamic guide camera for Kia Carnival IV (2020-2024)

Get access

AC INVERTER (LUGGAGE) AC INVERTER (REAR) AC INVERTER MODULE AMP (BOSE) BLK WIRE DRIVER SEAT BELT BUCKLE SENSOR HIGH MOUNTED STOP LAMP LEFT REAR COMBINATION LAMP (IN) LICENSE LAMP NCA WIRE PASSENGER OCCUPANT DETECTION SENSOR PASSENGER SEAT BELT BUCKLE SENSOR POWER SLIDING DOOR MODULE POWER TAILGATE BUZZER POWER TAILGATE INNER SWITCH REAR VIEW CAMERA REAR WIPER MOTOR RIGHT REAR COMBINATION LAMP (IN) SRS CONTROL MODULE TAILGATE LATCH TAILGATE SWITCH W/ DYNAMIC GUIDE CAMERA W/ POWER TAILGATE W/ SURROUND VIEW MONITOR W/O DYNAMIC GUIDE CAMERA W/O POWER TAILGATE W/O SURROUND VIEW MONITOR WINDSHIELD GLASS HEATER

Go to component: -> Ground distribution circuit (10 of 10) -> W/O DYNAMIC GUIDE CAMERA

Wiring diagram w/o dynamic guide camera (3 of 3)

Wiring diagram w/o dynamic guide camera for Kia Carnival IV (2020-2024)

Get access

AIR BAG 2 FUSE BLU/BLK WIRE BLU/ORG WIRE BRAKE SWITCH FUSE BRN WIRE CRASH PAD SWITCH CRASH PAD SWITCH (LOWER) DOOR LOCK FUSE DOOR LOCK RELAY DOOR UNLOCK RELAY DRIVER POWER OUTSIDE MIRROR FROM B+1 FUSE (DIAGRAM 3 OF 12) FROM B+3 FUSE (DIAGRAM 1 OF 12) GRN WIRE GRN/BLK WIRE GRY WIRE HIGH MOUNTED STOP LAMP IBU IBU 2 FUSE ICU-A ICU-B ICU-C ICU-D ICU-F ICU-G LEFT REAR COMBINATION LAMP (IN) LEFT REAR COMBINATION LAMP (OUT) LEFT REAR TURN SIGNAL LAMP LICENSE LAMP MODULE 9 FUSE NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER POWER OUTSIDE MIRROR REAR VIEW CAMERA RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT REAR COMBINATION LAMP (IN) RIGHT REAR COMBINATION LAMP (OUT) RIGHT REAR TURN SIGNAL LAMP S/HEATER (REAR RH) FUSE SRS CONTROL MODULE STOP LAMP SWITCH TAILGATE OPEN FUSE TAILGATE OPEN RELAY TO LONG TERM LOAD LATCH RELAY (DIAGRAM 7 OF 12) TRAILER CONNECTOR TWO TURN UNLOCK RELAY W/ AIR VENTILATION W/ DYNAMIC GUIDE CAMERA W/ SURROUND VIEW MONITOR W/O AIR VENTILATION W/O DYNAMIC GUIDE CAMERA W/O SURROUND VIEW MONITOR WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> Power distribution circuit (5 of 12) -> W/O DYNAMIC GUIDE CAMERA
