Kia Carnival IV (2020-2024) w/ walk-in w/o walk-in, air ventilation Wiring diagram

This page shows the only wiring diagram for the component.w/ walk-in w/o walk-in, air ventilation, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram w/ walk-in w/o walk-in, air ventilation (1 of 1)

Wiring diagram w/ walk-in w/o walk-in, air ventilation for Kia Carnival IV (2020-2024)

Get access

BLK WIRE DRIVER DOOR MODULE LEFT REAR SEAT MULTIMEDIA MONITOR NCA WIRE PASSENGER DOOR MODULE PASSENGER POWER OUTSIDE MIRROR PASSENGER POWER SEAT SWITCH PASSENGER POWER WINDOW SWITCH PASSENGER SAFETY POWER WINDOW MODULE PASSENGER WALK IN SWITCH PASSENGER WALK-IN MODULE REAR POWER OUTLET RIGHT POWER SLIDING DOOR SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SAFETY POWER WINDOW MODULE RIGHT REAR SAFETY POWER WINDOW SWITCH RIGHT REAR SEAT MULTIMEDIA MONITOR W/ AIR VENTILATION W/ AUTO UP/DOWN, SAFETY W/ WALK IN W/ WALK-IN W/O WALK-IN, AIR VENTILATION W/O AIR VENTILATION W/O AUTO UP/DOWN, SAFETY W/O WALK IN W/O WALK-IN, W/ AIR VENTILATION YEL WIRE

Go to component: -> Ground distribution circuit (6 of 10) -> W/ WALK-IN W/O WALK-IN, AIR VENTILATION
