Kia Carnival IV (2020-2024) rr lp t/ sig rl lp t/ sig rl lp tail exit rr lp tail exit Wiring diagram

AUTO B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRAKE SWITCH FUSE BRN WIRE COMPUTER DATA LINES SYSTEM FL LP T/ SIG FR LP TAIL EXIT FL LP TAIL EXIT FR LP T/ SIG GND (BCM) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HMSL HOT AT ALL TIMES IBU ICU JUNCTION BLOCK ICU JUNCTION BLOCK ECU GND ICU-A ICU-C ICU-D ICU-F ICU-H IPS 2 IPS 3 IPS 4 IPS 5 IPS 6 IPS CONTROL MODULE LEFT FULL TURN LEFT LANE CHANGE LH LP BRK LH TURN LAMP ACTR LH TURN LAMP TELLTALE LH TURN LP SW SIG LIGHT SW OUT LIGHT SW SIG MULTI-FUNCTION SWITCH (STEERING COLUMN ASSEMBLY) OFF PNK WIRE RED WIRE RH LP BRK RH TURN HAZARD LP SW SIG RH TURN LAMP ACTR RH TURN LAMP TELLTALE RH TURN LP SW SIG GND RIGHT END OF DASH) RIGHT FULL TURN RIGHT LANE CHANGE RR LP T/ SIG RL LP T/ SIG RL LP TAIL EXIT RR LP TAIL EXIT SELF RETURN HAZARD SW IND SW STOP LP SW WIPER, LIGHT GND TAIL W/ PROJECTION TYPE WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE
