Kia Carnival IV (2020-2024) pdw sw mode Wiring diagram
This page shows the only wiring diagram for the component.pdw sw mode, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pdw sw mode (1 of 1)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
FRONT UPPER CONSOLE SWITCH
GRN WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/ORG WIRE
IBU
ICU JUNCTION BLOCK
ICU-F
ILL
LEFT FORWARD PARKING DISTANCE WARNING SENSOR
LEFT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER)
LIN
MODULE 3 FUSE
PDW FWD PWR
PDW REV PWR
PDW SENS GROUND
PDW SW IND
PDW SW MODE
PDW SWITCH
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR
RIGHT FORWARD PARKING DISTANCE WARNING SENSOR (CENTER)
YEL WIRE
Go to component: -> Parking assistant circuit, w/o adas (1 of 2) -> PDW SW MODE
