Kia Carnival IV (2020-2024) passenger slide motor Wiring diagrams

This page contains all the electrical diagrams for the component. passenger slide motor, in which he is found in the car Kia Carnival IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram passenger slide motor (1 of 2)

Wiring diagram passenger slide motor for Kia Carnival IV (2020-2024)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BWD DOWN GRN WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C MEMORY POWER P/SEAT PASS FUSE PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER POWER SEAT SWITCH PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR POWER GROUND RED WIRE W/ SEAT WARMER W/O SEAT WARMER YEL WIRE YEL/RED WIRE

Go to component: -> Passenger power seat circuit, w/o walk-in switch -> PASSENGER SLIDE MOTOR

Wiring diagram passenger slide motor (2 of 2)

Wiring diagram passenger slide motor for Kia Carnival IV (2020-2024)

Get access

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BWD DOWN GRN WIRE GRN/WHT WIRE GROUND HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-C LT GRN WIRE MEMORY POWER P/SEAT PASS FUSE PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER POWER SEAT SWITCH PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR PASSENGER WALK IN SWITCH PASSENGER WALK-IN MODULE POWER GROUND RECLINING (BWD) UP RECLINING FWD RECLINING MTR RECLINING MTR (BWD) POWER GROUND RECLINING MTR (FWD) POWER GROUND RECLINING MTR SWITCH (BWD) RECLINING MTR SWITCH (FWD) RED WIRE SLIDE (FWD) UP SLIDE BWD SLIDE MOTOR SLIDE MOTOR (BWD) SLIDE MOTOR (FWD) SLIDE MOTOR SWITCH (BWD) SLIDE MOTOR SWITCH (FWD) WALK IN RECLINING MTR (BWD) WALK IN RECLINING MTR (FWD) WALK IN SLIDE MTR (BWD) WALK IN SLIDE MTR (FWD) WHT WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component: -> Passenger power seat circuit, w/ walk-in switch -> PASSENGER SLIDE MOTOR
