Kia Carnival IV (2020-2024) passenger front side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger front side impact sensor, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger front side impact sensor (1 of 1)
AIR BAG IND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER CURTAIN AIR BAG
DRIVER DOOR SIDE IMPACT PRESSURE SENSOR
DRIVER FRONT SIDE IMPACT SENSOR
DRIVER REAR SIDE IMPACT SENSOR
DRIVER SEAT BELT BUCKLE SENSOR
DRIVER SEAT BELT PRETENSIONER
DRIVER SIDE AIR BAG
E-CAN TRANSCEIVER
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
INSTRUMENT CLUSTER
MICOM
ORG/ WIRE
ORG/BLK WIRE
PASSENGER CURTAIN AIR BAG
PASSENGER DOOR SIDE IMPACT SENSOR
PASSENGER FRONT SIDE IMPACT SENSOR
PASSENGER REAR SIDE IMPACT SENSOR
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SEAT BELT PRETENSIONER
PASSENGER SIDE AIR BAG
RED WIRE
RED/ORG WIRE
SEAT BELT IND
SRS CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Supplemental restraints circuit (2 of 2) -> PASSENGER FRONT SIDE IMPACT SENSOR
