Kia Carnival IV (2020-2024) lower crash pad switch Wiring diagram
This page shows the only wiring diagram for the component.lower crash pad switch, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lower crash pad switch (1 of 1)
AWAY CLOSE SWITCH
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
E-CAN TRANSCEIVER
E/R JUNCTION BLOCK
FULL LOCK SWITCH
FULL OPEN SWITCH
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
HALF OPEN SWITCH
HALL SENS 1 -
HALL SENS 2
HALL SENS GND
HALL SENS-PWR
HOME POSITION SWITCH
HOT AT ALL TIMES
ILL
INNER SWITCH
INSTRUMENT CLUSTER
LOWER CRASH PAD SWITCH
MICOM
MULTI FUSE 1
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
POWER TAIL GATE FUSE
POWER TAILGATE INNER SWITCH
POWER TAILGATE LATCH
PTG HOLD SWITCH
RED WIRE
RIGHT POWER TAILGATE SPINDLE
SHIELD
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power tailgate circuit (2 of 2) -> LOWER CRASH PAD SWITCH
