Kia Carnival IV (2020-2024) electronic atm shift lever indicator Wiring diagram
This page shows the only wiring diagram for the component.electronic atm shift lever indicator, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic atm shift lever indicator (1 of 1)
A/V, NAVIGATION HEAD UNIT
ADAS UNIT
ATM SHIFT LEVER
ATM SHIFT LEVER INDICATOR
BLK BLK WIRE
BLK WIRE
BLK/ORG WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
CABIN UNIT SHIELD
CRASH PAD SWITCH
CRASH PAD SWITCH (LOWER)
DATA LINK CONNECTOR
ELECTRIC PARKING BRAKE SWITCH
ELECTRONIC ATM SHIFT LEVER INDICATOR
FRONT MONITOR
FRONT UPPER CONSOLE SWITCH
GLOVE BOX LAMP)
GRN/BLK WIRE
HAZARD SWITCH
IBU
IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH
KEYBOARD
LEFT MIC (SHIELD)
LEFT/RIGHT MIC SHIELD
MULTIMEDIA JACK (USB)
NCA WIRE
ORG/BLK WIRE
RED WIRE
RIGHT END OF DASH)
START-STOP BUTTON
W/ NAVIGATION
W/ ROA
W/ RVM W/O REAR VIEW, DYNAMIC CAMERA
W/ SBW
W/ SMART KEY
W/O BOSE AMP
W/O NAVIGATION
W/O PCA/ RSPA
W/O RVM, PCA
W/O SMART KEY
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component: -> Ground distribution circuit (2 of 10) -> ELECTRONIC ATM SHIFT LEVER INDICATOR
