Kia Carnival IV (2020-2024) door lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. door lock switch, in which he is found in the car Kia Carnival IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door lock switch (1 of 3)
Go to component -> Power windows circuit, w/ driver auto up/down & safety power windows (2 of 2) -> DOOR LOCK SWITCH
Wiring diagram door lock switch (2 of 3)
Go to component -> Power windows circuit, w/ front auto up/down & safety power windows (2 of 2) -> DOOR LOCK SWITCH
Wiring diagram door lock switch (3 of 3)
Go to component -> Power windows circuit, w/ front/rear auto up/down & safety power windows (2 of 2) -> DOOR LOCK SWITCH
