Kia Carnival IV (2020-2024) brake test Wiring diagram
This page shows the only wiring diagram for the component.brake test, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake test (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE LIGHT
BRAKE TEST
E/R JUNCTION BLOCK
ESC 1 FUSE
ESC 2 FUSE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
IBU
INPUT
MULTI FUSE (TYPE A)
MULTI FUSE (TYPE B)
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SCU (SHIFT BY WIRE CONTROL UNIT)
SWITCH
VEHICLE SPEED
WHT WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component: -> Anti-lock brakes circuit (2 of 3) -> BRAKE TEST
