Kia Carnival IV (2020-2024) bcw lamp wiring diagram
This page shows the only wiring diagram for the component.bcw lamp, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
bcw lamp wiring diagram (1 of 1)
B+3 FUSE
BCW IND
BCW LAMP
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER POWER OUTSIDE MIRROR
E-CAN HIGH
E-CAN LOW
E/R JUNCTION BLOCK
GRN WIRE
GROUND
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-B
ICU-C
L-CAN HIGH
L-CAN LOW
LEFT REAR RADAR
LH BCW IND
MEMORY POWER
MODULE 3 FUSE
NCA WIRE
ON/START INPUT
ORG/ WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
RED WIRE
RELAY ENERGIZED
RH BCW IND
RIGHT REAR RADAR
YEL WIRE
YEL/ORG WIRE
Go to component -> Blind spot information system circuit -> BCW LAMP
