Kia Carnival IV (2020-2024) ac inverter module Wiring diagram

This page shows the only wiring diagram for the component.ac inverter module, which is found in the car Kia Carnival IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram ac inverter module (1 of 1)

Wiring diagram ac inverter module for Kia Carnival IV (2020-2024)

Get access

AC INVERTER (LUGGAGE) AC INVERTER (REAR) AC INVERTER MODULE AMP (BOSE) BLK WIRE DRIVER SEAT BELT BUCKLE SENSOR HIGH MOUNTED STOP LAMP LEFT REAR COMBINATION LAMP (IN) LICENSE LAMP NCA WIRE PASSENGER OCCUPANT DETECTION SENSOR PASSENGER SEAT BELT BUCKLE SENSOR POWER SLIDING DOOR MODULE POWER TAILGATE BUZZER POWER TAILGATE INNER SWITCH REAR VIEW CAMERA REAR WIPER MOTOR RIGHT REAR COMBINATION LAMP (IN) SRS CONTROL MODULE TAILGATE LATCH TAILGATE SWITCH W/ DYNAMIC GUIDE CAMERA W/ POWER TAILGATE W/ SURROUND VIEW MONITOR W/O DYNAMIC GUIDE CAMERA W/O POWER TAILGATE W/O SURROUND VIEW MONITOR WINDSHIELD GLASS HEATER

Go to component: -> Ground distribution circuit (10 of 10) -> AC INVERTER MODULE
