Starting circuit, w/ smart key for Kia Carnival III (2014-2021)

Starting circuit, w/ smart key

Get access

ALT FUSE ALTERNATOR BATTERY BATTERY JUNCTION BLOCK BLK WIRE BLU WIRE C-CAN HIGH C-CAN LOW COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK ENGINE GRN WIRE ORG/ WIRE ORG/BLK WIRE P/N SWITCH (P, N POSITION: SW CLOSE) PCM PNK WIRE RED WIRE RLY CTRL SIG OUTPUT SMART KEY CONTROL MODULE SSB SW 1 SSB SW 2 START FEEDBACK SIG START MOTOR START RELAY START RLY START SOLENOID START/STOP BUTTON SWITCH TRANSMISSION RANGE SWITCH YEL WIRE YEL/ORG WIRE
