Auto headlamps leveling system (ahls) circuit for Kia Carnival III (2014-2021)
Auto headlamps leveling system (ahls) circuit
ACTUATOR OUTPUT
AUTO HEADLAMP LEVELING DEVICE MODULE
B+4 FUSE
B-CAN
BLK WIRE
BLU WIRE
BODY K-LINE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
E/R JUNCTION BLOCK
GROUND
GRY WIRE
HEADLAMP LOW SIGNAL
HEADLAMPS CIRCUIT
HIGH LOW
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-D
I/P-H I/P-A
IPS 3 CONTROL
IPS CONTROL MODULE
LEFT "C" PILLAR)
LEFT HEADLAMP LEVELING DEVICE ACTUATOR
MODULE 4 FUSE
ON/START INPUT
ORG/ WIRE
RED WIRE
RIGHT HEADLAMP LEVELING DEVICE ACTUATOR
SMART JUNCTION BLOCK
VEHICLE SPEED INPUT
WHT WIRE
YEL WIRE
