Electronic power steering circuit for Kia Carnival III (2014-2021)
Electronic power steering circuit
BLK WIRE
BLU WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
E/R-A
E/R-C
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-G
INSTRUMENT CLUSTER
INTERFACE
MDPS FUSE
MDPS IND
MDPS UNIT (RACK)
MEMORY PWR
MICOM
NCA WIRE
NOT USED NOT USED
ON START INPUT
ORG/ WIRE
PCB BLOCK
RED WIRE
SMART JUNCTION BLOCK
