Kia Carnival III (2014-2021) trailer lamp Wiring diagrams
This page contains all the electrical diagrams for the component. trailer lamp, in which he is found in the car Kia Carnival III (2014-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trailer lamp (1 of 3)
BLK WIRE
BLU WIRE
BRAKE LAMP
BRAKE SWITCH FUSE
BRAKE TEST
BRN WIRE
CIRCUIT
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
ESC UNIT ESC MODULE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-G
INSTRUMENT CLUSTER
INTERFACE
LEFT TURN IND
LEFT TURN LAMP
M-CAN
MICOM
MODULE 3 FUSE
NCA WIRE
ORG/BLK WIRE
PCM
RED WIRE
RIGHT TURN IND
RIGHT TURN LAMP
SMART JUNCTION BLOCK
SMART KEY CONTROL MODULE
STOP LAMP
STOP LAMP SWITCH
SWITCH
SWITCH "L" SIGNAL
TAIL LAMP
TAIL ON IND
TRAILER LAMP
TRANSCEIVER/
WHT/BLK WIRE
Go to component -> Exterior lamps circuit (4 of 4) -> TRAILER LAMP
Wiring diagram trailer lamp (2 of 3)
