Kia Carnival III (2014-2021) sirius out b+ Wiring diagrams

This page contains all the electrical diagrams for the component. sirius out b+, in which he is found in the car Kia Carnival III (2014-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram sirius out b+ (1 of 4)

Wiring diagram sirius out b+ for Kia Carnival III (2014-2021) (1 of 4)

Get access

AGC AM/FM AM/FM B+ AM/FM OUT ANT-R AUDIO AUX DET AUX L IN AUX R IN AUX REF BLK WIRE BLK/ORG WIRE BLU WIRE BPF BRN WIRE CAMERA B+ CAMERA DET CAMERA P GND CAMERA V/GND CAMERA V/IN COMBINATION ANTENNA FL (-) FR (-) GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN ON I/P-D LPF MATCHING CIRCUIT MATCHING RFC CIRCUIT MIC (IN OVERHEAD CONSOLE) MIC - MODULE 5 FUSE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/ORG WIRE RFC RL (+) RR (-) SIRIUS SIRIUS OUT B+ SMART JUNCTION BLOCK USB D- USB VOD WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/o navigation, display & amplifier (2 of 3) -> SIRIUS OUT B+

Wiring diagram sirius out b+ (2 of 4)

Wiring diagram sirius out b+ for Kia Carnival III (2014-2021) (2 of 4)

Get access

AGC AM/FM AM/FM B+ AM/FM OUT ANT-R AUDIO AUX DET AUX L IN AUX R IN AUX REF BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BPF BRN WIRE CAMERA B+ CAMERA DET CAMERA P GND CAMERA V/GND CAMERA V/IN COMBINATION ANTENNA GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN ON I/P-D LPF MATCHING CIRCUIT MIC (IN OVERHEAD CONSOLE) MIC - MODULE 5 FUSE NCA WIRE PNK WIRE RED WIRE RED/ORG WIRE RFC SIRIUS SIRIUS OUT B+ SMART JUNCTION BLOCK SPDIF (-) SPDIF GND USB D- USB VOD WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/o navigation & display w/ amplifier (2 of 4) -> SIRIUS OUT B+

Wiring diagram sirius out b+ (3 of 4)

Wiring diagram sirius out b+ for Kia Carnival III (2014-2021) (3 of 4)

Get access

AGC AM/FM AM/FM B+ AM/FM OUT ANT-U AUDIO AUX DET AUX L IN AUX R IN AUX REF BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BPF BRN WIRE BRN/ORG WIRE CAMERA B+ CAMERA P GND CAMERA SHIELD GROUND CAMERA V/GND CAMERA V/IN COMBINATION ANTENNA CRUISE CONTROL SYSTEM GPS GPS OUT B+ GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN ON I/P-D LPF MATCHING CIRCUIT MIC (IN OVERHEAD CONSOLE) MIC - MODULE 5 FUSE NAVI VOICE (+) NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/ORG WIRE RFC SIRIUS SIRIUS OUT B+ SMART JUNCTION BLOCK SPDIF (-) SPDIF GND VEHICLE SPEED SIG WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/o navigation w/ display & amplifier (2 of 4) -> SIRIUS OUT B+

Wiring diagram sirius out b+ (4 of 4)

Wiring diagram sirius out b+ for Kia Carnival III (2014-2021) (4 of 4)

Get access

AGC AM/FM AM/FM B+ AM/FM OUT ANT-U AUDIO AUX DET AUX L IN AUX R IN AUX REF BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BPF BRN WIRE BRN/ORG WIRE CAMERA B+ CAMERA P GND CAMERA SHIELD GROUND CAMERA V/GND CAMERA V/IN COMBINATION ANTENNA CRUISE CONTROL SYSTEM FL (-) FR (-) GPS GPS OUT B+ GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN ON I/P-D LPF MATCHING CIRCUIT MIC (IN OVERHEAD CONSOLE) MIC - MODULE 5 FUSE NCA WIRE ORG/ WIRE PNK WIRE PNK/BLK WIRE RED WIRE RED/ORG WIRE RFC RL (+) RR (-) SIRIUS SIRIUS OUT B+ SMART JUNCTION BLOCK VEHICLE SPEED SIG WHT WIRE YEL WIRE YEL/ORG WIRE

Go to component -> Radio circuit, w/o navigation w/ display w/o amplifier (2 of 3) -> SIRIUS OUT B+
