Kia Carnival III (2014-2021) rly ctrl acc Wiring diagram
This page shows the only wiring diagram for the component.rly ctrl acc, which is found in the car Kia Carnival III (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rly ctrl acc (1 of 1)
ANTENNA 1 B+
ANTENNA 1 GND
ANTENNA 2 B+
ANTENNA 2 GND
ANTENNA 3 B+
ANTENNA 3 GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BUMPER ANTENNA B+
BUMPER ANTENNA GND
DRV DR ANTENNA GND
DRV DR ANTENNA PWR
E/R JUNCTION BLOCK
ECU FUSE
EXTERNAL BUZZER
GRN WIRE
GRN/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-E
I/P-G
I/P-H
IMMO B+
IMMO GND
LED ACC
LED IGN
MEMORY PWR CPU
MEMORY PWR LOAD
MODULE 6 FUSE
ORG/ WIRE
PASS DR ANTENNA GND
PASS DR ANTENNA PWR
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RLY CTRL ACC
SMART JUNCTION BLOCK
SMART KEY 2 FUSE
SMART KEY ANTENNA (INTERIOR 1)
SMART KEY ANTENNA (INTERIOR 2)
SMART KEY ANTENNA (INTERIOR 3)
SMART KEY BUMPER ANTENNA
SMART KEY CONTROL MODULE
SSB ILL GND
SSB ILL PWR
START RLY
STARTING/CHARGING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Immobilizer circuit, w/ smart key system (1 of 3) -> RLY CTRL ACC
