Kia Carnival III (2014-2021) ptg int Wiring diagram
This page shows the only wiring diagram for the component.ptg int, which is found in the car Kia Carnival III (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ptg int (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
CENTER ROOM LAMP
GRN WIRE
GRN/BLK WIRE
GROUND
GRY/ORG WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT "C" PILLAR)
LEFT FRONT VANITY LAMP
LEFT FRONT VANITY LAMP SWITCH
LEFT POWER SLIDING DOOR SWITCH
LEFT REAR DOOR SWITCH
PNK WIRE
POWER TAILGATE LATCH
POWER TAILGATE MODULE
PRIMARY SWITCH
PTG INT
RED/ORG WIRE
RIGHT FRONT VANITY LAMP SWITCH
RIGHT POWER SLIDING DOOR SWITCH
RIGHT REAR DOOR SWITCH
SWITCH
TAILGATE LATCH
TAILGATE OPEN SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/ORG WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> PTG INT
