Kia Carnival III (2014-2021) pass door Wiring diagrams
This page contains all the electrical diagrams for the component. pass door, in which he is found in the car Kia Carnival III (2014-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pass door (1 of 2)
AJAR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
DOOR DOOR LK UNLK
DOOR LK
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLK
DOOR UNLOCK RELAY
GRN/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-C
I/P-D
I/P-E
I/P-F
IPS CONTROL MODULE
LEFT "C" PILLAR)
LEFT SLIDING DOOR LOCK ACTUATOR
LR DOOR LK/
OPEN SW
PASS DOOR
PASS DR LK/
PASSENGER DOOR LOCK ACTUATOR
PNK WIRE
REAR LH (+)
REAR RH (+)
RED WIRE
RIGHT SLIDING DOOR LOCK ACTUATOR
RLY CTRL
RR DOOR LK/
SLIDING DOOR LOCK RELAY
SLIDING DOOR UNLOCK RELAY
SMART JUNCTION BLOCK
UNLK SIG
WHT WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit (2 of 3) -> PASS DOOR
Wiring diagram pass door (2 of 2)
AJAR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
DOOR DOOR LK UNLK
DOOR LK
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLK
DOOR UNLOCK RELAY
GRN/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-C
I/P-D
I/P-E
I/P-F
IPS CONTROL MODULE
LEFT "C" PILLAR)
LEFT SLIDING DOOR LOCK ACTUATOR
LR DOOR LK/
OPEN SW
PASS DOOR
PASS DR LK/
PASSENGER DOOR LOCK ACTUATOR
PNK WIRE
REAR LH (+)
REAR RH (+)
RED WIRE
RIGHT SLIDING DOOR LOCK ACTUATOR
RLY CTRL
RR DOOR LK/
SLIDING DOOR LOCK RELAY
SLIDING DOOR UNLOCK RELAY
SMART JUNCTION BLOCK
UNLK SIG
WHT WIRE
YEL/BLK WIRE
Go to component -> Power door locks circuit (2 of 3) -> PASS DOOR
