Kia Carnival III (2014-2021) lin/diagnostic data line Wiring diagram
This page shows the only wiring diagram for the component.lin/diagnostic data line, which is found in the car Kia Carnival III (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin/diagnostic data line (1 of 1)
ALTERNATOR COM
APS 1 GROUND
APS 2 GROUND
APS 2 POWER
APS 2 SIGNAL
BATTERY SENSOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
C/FAN (HIGH) CONTROL
C/FAN (LOW) CONTROL
CCV CONTROL
COOLING FANS SYSTEM
DOWN SHIFT
E/R-A
E/R-B
E/R-C
ECU 1 FUSE
ECU 2 FUSE
ECU 3 FUSE
ENGINE CONTROL RELAY
ENGINE CONTROL RELAY CONTROL
ENGINE CONTROL RELAY ON INPUT
ENGINE SPEED SIGNAL OUTPUT
FUEL PUMP FUSE
FUEL PUMP RELAY
FUEL PUMP RELAY CONTROL
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
IGN COIL FUSE
IMMO DATA LINE
LIN LINE
LIN/DIAGNOSTIC DATA LINE
MEMORY POWER
NCA WIRE
ORG/ WIRE
PCB BLOCK
PCM
PNK WIRE
RED WIRE
SELECT SWITCH
SENS
SENSOR 1 FUSE
SENSOR 2 FUSE
SENSOR 3 FUSE
SENSOR B FUSE
SENSOR GROUND
SENSOR POWER
SENSOR SIGNAL
START RELAY CONTROL
STARTING/CHARGING SYSTEM
W/O IMMO/SMART KEY W/ IMMO/SMART KEY
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.3l (3 of 9) -> LIN/DIAGNOSTIC DATA LINE
