Kia Carnival III (2014-2021) left cw Wiring diagrams
This page contains all the electrical diagrams for the component. left cw, in which he is found in the car Kia Carnival III (2014-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left cw (1 of 2)
A/V, NAVIGATION HEAD UNIT
ACC/ON INPUT
AUX DET
AUX GND
AUX L +
AUX L IN
AUX R +
AUX R IN
AUX REF
AUX, USB JACK
AVN GND
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
GRN WIRE
GRY WIRE
ILL
KEY LEFT
KEY RIGHT
KEYBOARD
LEFT CCW
LEFT CW
M-CAN HIGH
M-CAN LOW
MEMORY PWR
MIC -
MTS KEY
NCA WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/ORG WIRE
RIGHT CCW
RIGHT CW
SW GND
USB D-
USB GND
USB VCC
VEHICLE SPEED SIG
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (5 of 5) -> LEFT CW
