Kia Carnival III (2014-2021) injector control 3 Wiring diagram
This page shows the only wiring diagram for the component.injector control 3, which is found in the car Kia Carnival III (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram injector control 3 (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR (BANK 1 EXHAUST)
CAMSHAFT POSITION SENSOR (BANK 1 INTAKE)
CAMSHAFT POSITION SENSOR (BANK 2 EXHAUST)
CAMSHAFT POSITION SENSOR (BANK 2 INTAKE)
CVVT 1 (BANK 1/INTAKE) CONTROL
CVVT 2 (BANK 2/INTAKE) CONTROL
CVVT 3 (BANK 1/EXHAUST) CONTROL
CVVT 4 (BANK 2/EXHAUST) CONTROL
ETC MOTOR, +/-
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
IGNITION COIL CONTROL CYL 2
IGNITION COIL CONTROL CYL 4
IGNITION COIL CONTROL CYL 5
IGNITION COIL CONTROL CYL 6
INJECTOR CONTROL 1
INJECTOR CONTROL 2
INJECTOR CONTROL 3
INJECTOR CONTROL 4
INJECTOR CONTROL 5
INJECTOR CONTROL 6
NCA WIRE
OIL TEMPERATURE SENSOR
ORG/ WIRE
OUTPUT SPEED POWER
OXYGEN SENSOR 1 HEATER
OXYGEN SENSOR 2 HEATER
OXYGEN SENSOR 2 HIGH
OXYGEN SENSOR 2 LOW
OXYGEN SENSOR 3 HEATER
OXYGEN SENSOR 3 HIGH
OXYGEN SENSOR 3 LOW
OXYGEN SENSOR 4 HEATER
OXYGEN SENSOR 4 HIGH
PCM
PCSV CONTROL
PNK WIRE
RED WIRE
SENSOR GROUND
SENSOR POWER
SIGNAL
SOL POWER 1
SOL POWER 2
SPILL VALVE CONTROL
SS B
VFS LINE
VFS UD
VIS 1 CONTROL
VIS 2 CONTROL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 3.3l (6 of 9) -> INJECTOR CONTROL 3
