Kia Carnival III (2014-2021) drv height mtr sig Wiring diagram

B-CAN HIGH B-CAN LOW BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER HEIGHT MOTOR DRIVER IMS CONTROL MODULE (UNDER DRIVER'S SEAT) DRIVER RECLINING MOTOR DRIVER SLIDE MOTOR DRIVER TILT MOTOR DRV FRT HEIGHT ADJ SW DN DRV FRT HEIGHT ADJ SW UP DRV HEIGHT MTR DN DRV HEIGHT MTR SIG DRV HEIGHT MTR UP DRV RECLINING MTR FR DRV RECLINING MTR RR DRV RECLINING MTR SIG DRV RECLINING SW FR DRV RECLINING SW RR DRV RR HEIGHT ADJ SW DN DRV RR HEIGHT ADJ SW UP DRV SLIDE MTR FR DRV SLIDE MTR RR DRV SLIDE MTR SIG DRV SLIDE SW FR DRV SLIDE SW RR DRV TILT MTR DN DRV TILT MTR SIG DRV TILT MTR UP GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GROUND GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-C I/P-D LEAK CURRENT AUTO CUT DEVICE LEFT "C" PILLAR) MEMORY 2 FUSE MEMORY POWER MODULE 2 FUSE MODULE 4 FUSE ON/START POWER P/SEAT (DRV) FUSE PNK/BLK WIRE RED WIRE RED/GRN WIRE RED/WHT WIRE SENSOR POWER SMART JUNCTION BLOCK WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
