Kia Carnival III (2014-2021) c-can high local-can high Wiring diagram
This page shows the only wiring diagram for the component.c-can high local-can high, which is found in the car Kia Carnival III (2014-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-can high local-can high (1 of 1)
ANTI-LOCK BRAKES SYSTEM
BCM (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRAKE SWITCH
C-CAN HIGH
C-CAN HIGH LOCAL-CAN HIGH
C-CAN LOW
C-CAN LOW LOCAL-CAN LOW
COMPUTER DATA LINES SYSTEM
CRUISE FUSE
E/R-B
ESC MODULE
ESC UNIT
FL SIG
FL VCC
FR SIG
FR VCC
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT IN ON OR START
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
NCA WIRE
ON/START INPUT
ORG/ WIRE
PCB BLOCK
RED WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RL SIG
RL VCC
RR SIG
RR VCC
SMART CRUISE CONTROL RADAR
SMART KEY CONTROL MODULE
STOP LAMP SWITCH
VEHICLE SPEED INPUT
VEHICLE SPEED SIG
W/O AEB W/ AEB
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Cruise control circuit (3 of 3) -> C-CAN HIGH LOCAL-CAN HIGH
