Kia Cadenza II (2016-2020) w/o memory 10 way w/o memory 12 way w/ memory 10 way w/ memory 14 way Wiring diagram
This page shows the only wiring diagram for the component.w/o memory 10 way w/o memory 12 way w/ memory 10 way w/ memory 14 way, which is found in the car Kia Cadenza II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o memory 10 way w/o memory 12 way w/ memory 10 way w/ memory 14 way (1 of 1)
10-WAY 12-WAY
BLK WIRE
DRIVER AIR VENTILATION SEAT BLOWER MOTOR
DRIVER DOOR LAMP
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR MODULE
DRIVER IMS MODULE
DRIVER POWER OUTSIDE MIRROR
DRIVER RECLINING LIMIT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MANUAL SWITCH
DRIVER SMART KEY OUTSIDE HANDLE
FUEL FILLER ACTUATOR
FUEL PUMP CONTROL MODULE
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR DOOR LOCK ACTUATOR
LEFT REAR POWER WINDOW SWITCH
NCA WIRE
ORG/ WIRE
PASSENGER OCCUPANT DETECTION SENSOR
PASSENGER SEAT BELT BUCKLE SWITCH
POWER TRUNK MODULE
RED WIRE
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (IN)
SRS CONTROL MODULE
SUNROOF CONTROL UNIT (GLASS)
SUNROOF CONTROL UNIT (ROLLER)
TRUNK LID LATCH
W/ MEMORY
W/ MEMORY, W/O MEMORY, 10 WAY, 12 WAY
W/ SMART KEY
W/O MEMORY 10 WAY W/O MEMORY 12 WAY W/ MEMORY 10 WAY W/ MEMORY 14 WAY
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> W/O MEMORY 10 WAY W/O MEMORY 12 WAY W/ MEMORY 10 WAY W/ MEMORY 14 WAY
