Kia Cadenza II (2016-2020) rear fog lamp Wiring diagrams
This page contains all the electrical diagrams for the component. rear fog lamp, in which he is found in the car Kia Cadenza II (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear fog lamp (1 of 2)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DEDICATED DRL LH
DEDICATED DRL RH
ESC UNIT ESC MODULE
FOG LAMP SWITCH SIG
FOG LP FRT LH
FOG LP FRT RH
FR FOG
GATEWAY
GND (FOG LAMP)
GND GND (BCM)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
H/LP
H/LP H/LP LO HI LH LH
H/LP LO HI RH RH
HDLP LOW SIG
HEADLAMP
HEADLAMP HIGH SWITCH OUT
HEADLAMP LOW BACKUP
HOT IN ON OR START
I/P-A
I/P-B
I/P-C
I/P-D
I/P-F
IGPM
IPS CONTROL MODULE
LEFT FRONT FOG LAMP
LEFT REAR COMBINATION LAMP (IN)
LIGHT SWITCH OUT
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PARKING BRK SW
PASS
PNK WIRE
REAR FOG LAMP
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT FRONT FOG LAMP
RIGHT REAR COMBINATION LAMP (IN)
RR FOG
RR FOG LAMP
SWITCH OUT
TAIL AUTO DIMMER
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Autolamps circuit (1 of 2) -> REAR FOG LAMP
Wiring diagram rear fog lamp (2 of 2)
