Kia Cadenza II (2016-2020) on/start power wiring diagram
This page shows the only wiring diagram for the component.on/start power, which is found in the car Kia Cadenza II (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
on/start power wiring diagram (1 of 1)
ACTUATOR OUTPUT
ANALOG
AUTO HEADLAMP LEVELING DEVICE MODULE
B+3 FUSE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU/BLK WIRE
BODY K-LINE
COMPUTER DATA LINES SYSTEM
CONTROL
CRUISE CONTROL SYSTEM
DC MOTOR +
E/R JUNCTION BLOCK
EEPROM
GATEWAY
GENERATOR
GRN WIRE
GROUND
GRY WIRE
HEADLAMP LOW SIG
HOT AT ALL TIMES
HOT IN ON OR START
I/P-A
I/P-C
I/P-D
I/P-F
IGPM
INPUT
K LINE
LEFT HEADLAMP
MICOM
MODULE 6 FUSE
MULTI FUSE (TYPE A)
ON/START POWER
ORG/ WIRE
PNK WIRE
PWM
REGULATOR
RESET+
RIGHT HEADLAMP
SPEED SIG
VOLTAGE
WHT WIRE
YEL WIRE
Go to component -> Auto headlamps leveling system (ahls) circuit -> ON/START POWER
