Kia Cadenza I facelift (2013-2016) stop button switch Wiring diagram
This page shows the only wiring diagram for the component.stop button switch, which is found in the car Kia Cadenza I facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop button switch (1 of 1)
A/V, NAVIGATION HEAD UNIT
A/V, NAVIGATION HEAD UNIT SHIELD
AUX, USB JACK
BLK WIRE
COOLING FAN CONTROLLER
CRASH PAD SWITCH TILT, TELESCOPIC ANALOG SWITCH CLOCK
DATA LINK CONNECTOR
ESC MODULE
FRONT MONITOR
GND SIG
I/P-G
INSTRUMENT CLUSTER
JOINT CONNECTOR
MDPS UNIT
MTS MODULE
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
REAR CURTAIN MODULE
RHEOSTAT
RIGHT FRONT HOOD FOG LAMP SWITCH RIGHT HEADLAMP
RIGHT HORN
STANDARD PREMIUM
STEERING ANGLE SENSOR
STOP BUTTON SWITCH
TILT, TELESCOPIC MODULE
TRUNK LID SWITCH
W/O MTS W/ MTS
WASHER (LEFT TOP LEVEL OF DASH) SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (3 of 5) -> STOP BUTTON SWITCH
